Type: 3-way 2-way full-range bass-reflex
Components:HF:2x1.4″neo;LF:1x12″neo
Coverage Pattern(-6dB):100°H×10°V
Frequency Response(-10dB)：65Hz—20KHz
Sensitivity(1W@1m):98dB
Max SPL (peak):125dB@450W(128dB@900W)
Impedance:8 ohms
Power Handling(AES/Peak):450W/ 900W
Frequency division mode:Active
Connector:SPEAKON NL4×2
Box material:15mm High-quality plywood
Dimensions:W580*D468*H330mm
Weight:22.3kg
