Type:2-unit 2-way rear-guide speaker
Components:HF:1x1.4″;LF:1x10″
Coverage Pattern(-6dB):90°H×60°V
Frequency Response(-10dB):55Hz—23KHz
Sensitivity(1W@1m):95dB
Max SPL (peak):122dB@300w(128dB@1400w)
Impedance:8 ohms
Power Handling(AES/Peak):300W /1400W
Frequency division mode:Passive
Connector:SPEAKON NL4×1
Box material:15mm Birch plywood
