Type:2-unit 2-way rear-guide speaker
Components:HF:1x1.7″;LF:1x12″
Coverage Pattern(-6dB):90°H×60°V
Frequency Response(-10dB):52Hz—20KHz
Sensitivity(1W@1m):97dB
Max SPL (peak):129dB
Impedance:8 ohms
Power Handling(AES/Peak):400W /1400W
Frequency division mode:Passive
Connector:SPEAKON NL4×2
Box material:15mm Birch plywood
Dimensions:W377mm*D400mm*H605mm
Weight:24kg
