Type:2-unit 2-way speaker
Components:HF:1x1.7″;LF:1x12″
Coverage Pattern(-6dB):90°H×40°V
Frequency Response(-10dB):56Hz—20KHz
Sensitivity(1W@1m):97dB
Max SPL (peak):123dB@400W(126dB@800W)
Impedance:8 ohms
Power Handling(AES/Peak):400W /1600W
Frequency division mode:Passive
Connector:SPEAKON NL4×2
Box material:15mm Birch plywood
Dimensions:W605*D417*H308.9mm
Weight:18.8kg
